Product


NT

Item:  NT
Type: Gas Scooter
Max. Speed:  45KM/H; 85 (kn/h)
Displacement: 50CC; 125cc; 150cc; 175cc

0
Views: 133
Detail image:
Specifications
ModelMT 50CC(EURO 5)MT 125cc(EURO 5)MT 150ccMT 175cc
Dimension1900*720*1130(mm)1900*720* 1130(mm)1900*720,1130(mm)1900*720*1130(mm)
Wheel Base1320(mm)1320(mm)1320(mm)1320(mm)
Front Tire120/90-10120/90-10120/90-10120/90-10
Rear Tire120/90-10120/90-10120/90-10120/90-10
SpeedometerDIGITALDIGITALNORMAL or DIGITALNORMAL or DIGITAL
Ignition methodsRONGMAO EFIRONGMAO EFICDICDI
Brake StyleFront: Disk, Rear: DrumCBS Front: Disk, Rear: DrumFront: Disk, Rear: DrumFront: Disk, Rear: Drum
Displancement49.6(ml)1246(ml)149.6(ml)168,9(ml)
Engne StyleGY6 single cylinder, 4 stroke. Air-cooledJ16,Single Cylinder, Air-cooied, 4-strokeSingle Cylinder, Air-cooled, 4-strokeSingle Cylinder, Air-cooled, 4-stroke
Bore*Stroke39×41.5(mm)52.4×57.8mm57.4×57.8(mm)61×57. 8m
Max. Power2.4/7500(Kw/r/min)6.2/7500 (Kw/r/min)5.8/7500(Kw/r/min)8.3/8000 (Kw/r/min)
Max. Torque3.0/5000(N.m/r/min)9.0/6000 (Kv/r/min)7.8/6000(N.m/f/min)11.0/6000(Kw/r/min)
Compression Ratio10.5:19.2:19.5:19.2:1
Starting TypeElectric/KickElectricy/KickEiectric/KickElectric/Kick
Max. Speed45KM/H85 (kn/h)85 (km/h)85 (km/h)
