Navigator 500
7+
Views: 589
Detail image:
Specifications
ClassificationComfigurationsParameter
Basis ParameterModel Name Navigator 500S
Brand Jiajue
QuotationsUS$2,650
Model OriationSport Cruiser
Engine ModeHorizone Cylinder、Four Stroke、Water Cooled、OHC、Four Vavle
Max Power(kw28/8500
Max Torque(N.m)34/6000
Seat Height(mm)760
Engine ParameterDisplacement(mL)494ML
Engine Bore(mm)70*64.2
Fuel SupplyDelphi EFI
Ratio 11:1
100KM Accerations6S
Max Speed(km/h)160
Tank Capacity(L)>20
Average Oil Consumption(L/100km)4.3
MIleage(km)500
Emmsion stardard
Fuel type95#
Power Input Transmission ModeNormally Toothed Two-Stage Transmission with six Gear
Cluth TypeWet Multi-disc Clutch
Transmission ModeChain
Model ParameterLengthxWidethxHeigth(mm)2225*875*1150
N.W(kg)190
G.W(kg)214
Frame Steel Tube Cradle Frame
Rear ArmPress Sheel Metal One piece
Wheel Base(mm)1600
Clearance(mm)120
Headlight LED
Tail LightLED
SpeedometerTFT Colors Board
Leaning Angle(°)29.1
Drag Form(mm)116
Minimum Turning(m)200
Max load(kg)150
Optional ColorsGradient Red,Gradient Green,Mat Black,Suzuki Red
Rim ParameterFront Rim120/70ZR17 M/C58W
Rear Rim180/55ZR17 M/C73W
Rim TypeAmilumilum Alloy
Tyre Semi-hot melt Vaccum Tire
Front Brake ModeΦ320mm Floating Double Disc Pare with four pistons
Rear Brake Mode Φ240mm Mono Disk with single piston
Front suspentions Φ42 Upside down Liquid Damping Shock Absorber
Rear SuspentionsMiddle Singe absorber
ABSYes
